NCP3063DR2G 1.5 A, Step−Up/Down/Inverting Switching Regulators bridge type rectifier diode

Features

• Operation to 40 V Input

• Low Standby Current

• Output Switch Current to 1.5 A

• Output Voltage Adjustable

• Frequency Operation of 150 kHz

• Precision 1.5% Reference

• New Features: Internal Thermal Shutdown with Hysteresis New Features: Cycle−by−Cycle Current Limiting

• Pb−Free Packages are Available

Applications

• Step−Down, Step−Up and Inverting supply applications

• High Power LED Lighting

• Battery Chargers

The NCP3063 Series is a higher frequency upgrade to the popular MC34063A and MC33063A monolithic DC−DC converters. These devices consist of an internal temperature compensated reference, comparator, a controlled duty cycle oscillator with an active current limit circuit, a driver and a high current output switch. This series was specifically designed to be incorporated in Step−Down, Step−Up and Voltage−Inverting applications with a minimum number of external components.
