    TT2170 Color TV Horizontal Deflection Output Applications integrated circuit components


    TT2170 Color TV Horizontal Deflection Output Applications


    Features

    High speed.

    High breakdown voltage(VCBO=1500V).

    High reliability(Adoption of HVP process).

    Adoption of MBIT process.

    On-chip damper diode.


    Specifications

    Absolute Maximum Ratings at Ta=25°C


    ParameterSymbolConditionsRatingsUnit
    Collector-to-Base VoltageVCBO1500V
    Collector-to-Emitter VoltageVCEO800V
    Collector-to-Emitter VoltageVEBO5V
    Collector CurrentIC5A
    Collector Current (Pulse)ICP12A
    Collector DissipationPC2.0W
    Tc=25°C25W
    Junction TemperatureTj150°C
    Storage TemperatureTstg--55 to +150°C

    Electrical Characteristics at Ta=25°C




    ParameterSymbolConditionsRatingsUnit
    mintypmax
    Collector Cutoff CurrentICBOVCB=800V, IE=010µA
    Collector Cutoff CurrentICESVCE=1500V, RBE=01.0mA
    Collector Sustain VoltageVCEO(sus)IC=100mA, IB=0800V
    Emitter Cutoff CurrentIEBOVBE=4V, IC=040130mA
    Collector-to-Emitter Saturation VoltageVCE(sat)IC=2.7A, IB=0.54A3V
    Base-to-Emitter Saturation VoltageVBE(sat)IC=2.7A, IB=0.54A1.5V
    DC Current GainhFE1VCE=5V, IC=0.5A10
    hFE2VCE=5V, IC=3A58
    Diode Forward VoltageVFIEC=4A2V
    Fall TimetfIC=1.8A, IB1=0.36A, IB2=--0.72A0.3µs
