    BTS134D Smart Low Side Power Switch electronic chip board

    BTS134D Smart Low Side Power Switch electronic chip board


    Features

    Logic Level Input

    Input Protection (ESD)

    Thermal shutdown with auto restart


    Green product (RoHS compliant)

    Overload protection

    Short circuit protection


    Overvoltage protection

    Current limitation

    Analog driving possible


    Application

    All kinds of resistive, inductive and capacitive loads in switching or linear applications µC compatible power switch for 12 V DC applications Replaces electromechanical relays and discrete circuits G


    Maximum Ratings at Tj = 25°C, unless otherwise specified

    ParameterSymbolValueUnit
    Drain source voltageVDS42V
    Supply voltage for full short circuit protectionVbb(SC)42V
    Continuous input voltage1)VIN-0.2 2) ... +10V
    Continuous input current2) -0.2V VIN 10V VIN < -0.2V or VIN > 10VINself limited | IIN | 2mA
    Operating temperatureTj-40 ...+150°C
    Storage temperatureTstg-55 ... +150°C
    Power dissipation 5) TC = 85 °C 6cm2 cooling area , TA = 85 °CPtot

    43

    1.1

    W
    Unclamped single pulse inductive energy 2)EAS3J
    Load dump protection VLoadDump2)3) = VA + VS VIN = 0 and 10 V, td = 400 ms, RI = 2 , RL = 4.5 , VA = 13.5 VVLD65V
    Electrostatic discharge voltage2) (Human Body Model) according to Jedec norm EIA/JESD22-A114-B, Section 4VESD2kV
