Transistors Resistor SMD 2512 RC2512JK-07180RL RC2512 Series

SCOPE

This specification describes RC2512 series chip resistors with lead-free terminations made by thick film process.

APPLICATIONS

z All general purpose application

FEATURES

z Saving of PCB space

z None forbidden-materials used in products/production

z Halogen Free Epoxy

zRoHS compliant - Products with lead free terminations meet RoHS requirements

- Pb-glass contained in electrodes, resistor element and glass are exempted by RoHS

zReducing environmentally hazardous wastes

z High component and equipment reliability

ORDERING INFORMATION - GLOBAL PART NUMBER & 12NC

Both part numbers are identified by the series, size, tolerance, packing type, temperature coefficient, taping reel and resistance value.

YAGEO BRAND ordering code GLOBAL PART NUMBER (PREFERRED)

RC2512 X R - XX XXXX L (1) (2) (3) (4) (5) (6)

(1) TOLERANCE

F = ±1% J = ±5% (for Jumper ordering, use code of J)

(2) PACKAGING TYPE R = Paper taping reel

(3) TEMPERATURE COEFFICIENT OF RESISTANCE – = Base on spec

(4) TAPING REEL 07 = 7 inch dia. Reel 10 = 10 inch dia. Reel 13 = 13 inch dia. Reel

(5) RESISTANCE VALUE There are 2~4 digits indicated the resistor value. Letter R/K/M is decimal point, no need to mention the last zero after R/K/M, e.g.1K2, not 1K20. Detailed resistance rules show in table of “Resistance rule of global part number”.

ORDERING EXAMPLE

The ordering code of a RC2512 chip resistor, value 180 X with ±5% tolerance, supplied in 7-inch tape reel is: RC2512JK-07180RL.

NOTE 1. All our RSMD products meet RoHS compliant and Halogen Free. "LFP" of the internal 2D reel label mentions "Lead Free Process"

2. On customized label, "LFP" or specific symbol can be printed

ELECTRICAL CHARACTERISTICS

ELECTRICAL CHARACTERISTICS CHARACTERISTICS

RC0805 1/8 W Operating Temperature Range –55 °C to +155 °C

Maximum Working Voltage 200 V

Maximum Overload Voltage 500 V

Dielectric Withstanding Voltage 500 V

5% (E24) 1 Ω to 22 MΩ

Resistance Range 1% (E24/E96) 1 Ω to 10 MΩ

Zero Ohm Jumper < 0.05 Ω

1 Ω ≤ R ≤ 10 Ω ±200 ppm/°C

Temperature Coefficient 10 MΩ < R ≤ 22 MΩ ±200 ppm/°C

10 Ω < R ≤ 10 MΩ ±100 ppm/°C

Rated Current 2 A Jumper Criteria

Maximum Current 5 A
