    CL21A475KPFNNNE High Voltage Ceramic Capacitors CAP 4.7㎌ 10V X5R 0805

    Ask Lasest Price
    Brand Name : Anterwell
    Model Number : CL21A475KPFNNNE
    Certification : Original Factory Pack
    Price : Negotiation
    Payment Terms : T/T, Western Union,PayPal
    Supply Ability : 150000PCS
    Delivery Time : 1 Day
    • Product Details
    • Company Profile

    CL21A475KPFNNNE High Voltage Ceramic Capacitors CAP 4.7㎌ 10V X5R 0805

    CL21A475KPFNNNE High Voltage Ceramic Capacitors CAP 4.7㎌ 10V X5R 0805


    SPECIFICATION (Reference sheet)

    · Supplier : Samsung electro-mechanics

    · Samsung P/N : CL21A475KPFNNNE

    · Product : Multi-layer Ceramic Capacitor

    · Description : CAP, 4.7㎌, 10V, ±10%, X5R, 0805


    CL 21 A 475 K P F N N N E

    ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪


    ① Series Samsung Multi-layer Ceramic Capacitor
    ② Size 0805 (inch code) L: 2.0 ± 0.1 mm W: ± 0.1 mm
    ③ Dielectric X5R
    ④ Capacitance 4.7 ㎌
    ⑤ Capacitance tolerance ±10 %
    ⑥ Rated Voltage 10 V
    ⑦ Thickness 1.25 ± 0.1 mm

    ⑧ Inner electrode Ni

    Termination Cu

    Plating Sn 100% (Pb Free)

    ⑨ Product Normal
    ⑩ Special Reserved for future use
    ⑪ Packaging Cardboard Type, 7" reel


    PerformanceTest condition
    CapacitanceWithin specified tolerance
    1㎑±10% 1.0±0.2Vrms
    Tan δ (DF)0.1 max
    Insulation Resistance

    10,000Mohm or 100Mohm⋅㎌

    Whichever is Smaller

    Rated Voltage 60~120 sec.
    AppearanceNo abnormal exterior appearanceMicroscope (×10)
    Withstanding VoltageNo dielectric breakdown or mechanical breakdown250% of the rated voltage
    Temperature CharacterisitcsX5R (From -55℃ to 85℃, Capacitance change shoud be within ±15%)

    D. Recommended Soldering method :


    Reflow ( Reflow Peak Temperature : 260+0/-5℃, 10sec. Max )


    Product specifications included in the specifications are effective as of March 1, 2013.

    Please be advised that they are standard product specifications for reference only.

    We may change, modify or discontinue the product specifications without notice at any time.

    So, you need to approve the product specifications before placing an order.

    Should you have any question regarding the product specifications, please contact our sales personnel or application engineers.


    ★ Capacitor/Resistor/Inductance SMD SIZE & PACKAGE ★
    International CodeSize CodeReel Quantity
    (pcs)
    Length
    (mm)
    Width
    (mm)
    Thickness
    (mm)
    010050402200000.250.1250.13
    02010603100000.60.30.3
    04021005100001.00±0.050.05±0.050.50±0.05
    060316084000-50001.60±0.100.80±0.100.80±0.10
    080520124000-50002.00±0.201.25±0.200.70±0.20
    1206321620003.20±0.301.60±0.200.70±0.20
    1210322520003.20±0.302.50±0.301.25±0.30
    1808452010004.50±0.402.00±0.202.00±0.30
    1812453210004.50±0.403.20±0.302.50±0.30
    1825456410004.50±0.406.40±0.400.61±0.36
    2225576410005.70±0.506.40±0.502.50±0.30
    251263325006.30±0.503.20±0.502.50±0.30
    303576904007.60±0.509.00±0.053.00±0.30
    case A321620003.20±0.201.60±0.201.60±0.20
    case B352820003.50±0.202.80±0.201.90±0.20
    case C60325006.00±0.203.20±0.202.60±0.20
    case D734350030±0.204.30±0.202.80±0.20
    case E7343H4007.30±0.204.10±0.204.00±0.20
