    Field Effect Transistor IC Chip

    Ask Lasest Price
    Brand Name : ALPHA
    Model Number : AO4408
    Certification : Original Factory Pack
    Price : Negotiation
    Payment Terms : T/T, Western Union,PayPal
    Supply Ability : 6000PCS
    Delivery Time : 1 Day
    • Product Details
    • Company Profile

    Field Effect Transistor IC Chip


    AO4408 N-Channel Enhancement Mode Field Effect Transistor


    General Description

    The AO4408/L uses advanced trench technology to provide excellent RDS(ON), low gate charge and fast switching. This device makes an excellent high side switch for notebook CPU core DC-DC conversion. AO4408 and AO4408L are electrically identical. -RoHS Compliant -AO4408L is Halogen Free


    Features

    VDS (V) = 30V

    ID = 12A (VGS = 10V)

    RDS(ON) < 13mΩ (VGS = 10V)

    RDS(ON) < 16mΩ (VGS = 4.5V)


    Thermal Characteristics

    ParameterSymbolTypMaxUnits
    Maximum Junction-to-Ambient At ≤ 10sRoja2340°C/W
    Maximum Junction-to-Ambient ASteady-State

    48

    65°C/W
    Maximum Junction-to-Lead CSteady-StateRojl1216°C/W
