High Frequency Rectifier Diodes Circuit Silicon 1SR154-400TF Electrical
Rectifier diode 1SR154-400
Applications
General rectification
Features
1) Small power mold type(PMDS)
2) High Reliability
Construction Silicon diffused junction
Absolute maximum ratings (Ta=25C)
Parameter | Symbol | Limits | Unit |
Reverse voltage (non-repetitive peak) | VRMS | 500 | V |
Reverse voltage (repetitive peak) | VR | 400 | V |
Average rectified forward current | Io | 1 | A |
Forward current surge peak (60Hz/1cyc) | IFSM | 30 | A |
Junction temperature | Tj | 150 | °C |
Storage temperature | Tstg | 55 to 150 | °C |
Electrical characteristics (Ta=25C)
Forward voltage VF - - 1.1 V IF=1A
Reverse current IR - - 10 uA VR=400V
![]() |
