Tab UP RJ45 Ethernet Jack JK0654219NL 10 / 100 / 1000 Base-T 1500 Vrms

Anterwell Technology Ltd.
Contact Now
    Buy cheap Tab UP RJ45 Ethernet Jack JK0654219NL 10 / 100 / 1000 Base-T 1500 Vrms from wholesalers

    Buy cheap Tab UP RJ45 Ethernet Jack JK0654219NL 10 / 100 / 1000 Base-T 1500 Vrms from wholesalers
    • Buy cheap Tab UP RJ45 Ethernet Jack JK0654219NL 10 / 100 / 1000 Base-T 1500 Vrms from wholesalers

    Tab UP RJ45 Ethernet Jack JK0654219NL 10 / 100 / 1000 Base-T 1500 Vrms

    Ask Lasest Price
    Brand Name : Pulse
    Model Number : JK0654219NL
    Certification : Original Factory Pack
    Price : Negotiate
    Payment Terms : T/T, Western Union,Paypal
    Supply Ability : 750pcs
    Delivery Time : 1
    • Product Details
    • Company Profile

    Tab UP RJ45 Ethernet Jack JK0654219NL 10 / 100 / 1000 Base-T 1500 Vrms

    Tab UP RJ45 Ethernet Jack JK0654219NL 10 / 100 / 1000 Base-T 1500 Vrms


    JK0654219NL

    RJ-45 Connectors With Integarted Magnetics


    Description:

    10/100/1000 Base-T RJ45 single port (1x1) Tab-UP with or without LEDs integrated magnetics connector (ICM), designed to support applications, such as Network Interface Cards (NIC), LAN-on-Motherboard (LOM), and PC applications.


    Features and Benefits:

    RoHS-5 peak wave solder temperature rating 235°C

    RoHS-6 peak wave solder temperature rating 260°C

    Suitable for CAT 5 and 6 Fast Ethernet cable or better UTP Electrical


    Performance Summary:

    Meets IEEE 802.3 specification 350µH minimum OCL with 8mA bias current

    High performance for maximum EMI suppression


    RJ45 Durability Testing Rating
    Part Number

    Mating Force

    (MAX)

    Unmating Force

    (MAX)

    DurabilityPlug to Jack
    JK Series5 lbs./2.268 kgs.5 lbs./2.268 kgs.750 Typ20lbs./9.072 kgs.
