BT136-600E Thyristor Product Catalog Triacs Sensitive Gate High Sensitivity
Features
· With TO-220AB package
· Glass passivated, sensitive gate triacs in a plastic envelope,
intended for use in general purpose bidirectional
switching and phase control applications,
where high sensitivity is required in all four quadrants.
QUICK REFERENCE DATA
SYMBOL | PARAMETER | VALUE | UNIT |
VDRM | Repetitive peak off-state voltage | 600 | V |
VRRM | Repetitive peak off-state voltage | 600 | V |
T(AV) | Average on-state current | 4 | A |
ITSM | Non-repetitive peak on-state current | 25 | A |
Tstg | Storage temperature | -45~150 | ℃ |
Tj | Operating junction temperature | ℃ |
![]() |
