    PIC18LF2520-I/ML Programmable IC Chips Enhanced Flash Microcontrollers with 10-Bit A/D and nanoWatt Technology


    PIC18LF2520-I/ML


    Programmable IC Chips Enhanced Flash Microcontrollers with 10-Bit A/D and nanoWatt Technology


    Power Managed Modes:


    • Run: CPU on, peripherals on

    • Idle: CPU off, peripherals on

    • Sleep: CPU off, peripherals off

    • Idle mode currents down to 5.8 µA typical

    • Sleep mode current down to 0.1 µA typical

    • Timer1 Oscillator: 1.8 µA, 32 kHz, 2V

    • Watchdog Timer: 2.1 µA

    • Two-Speed Oscillator Start-up


    Peripheral Highlights:


    • High-current sink/source 25 mA/25 mA

    • Three programmable external interrupts

    • Four input change interrupts

    • Up to 2 Capture/Compare/PWM (CCP) modules, one with Auto-Shutdown (28-pin devices)

    • Enhanced Capture/Compare/PWM (ECCP) module (40/44-pin devices only): - One, two or four PWM outputs - SelI/Oectable polarity - Programmable dead time - Auto-Shutdown and Auto-Restart

    • Master Synchronous Serial Port (MSSP) module supporting 3-wire SPI™ (all 4 modes) and I2C™ Master and Slave Modes

    • Enhanced Addressable USART module: - Supports RS-485, RS-232 and LIN 1.2 - RS-232 operation using internal oscillator block (no external crystal required) - Auto-Wake-up on Start bit - Auto-Baud Detect

    • 10-bit, up to 13-channel Analog-to-Digital Converter module (A/D): - Auto-acquisition capability - Conversion available during Sleep

    • Dual analog comparators with input multiplexing)


    DeviceProgram MemoryData MemoryI/O

    10-bit A/D

    (ch)

    CCP/ ECCP

    (PWM)

    Flash

    (bytes)

    Single-Word

    Instructions

    SRAM

    (bytes)

    EEPROM

    (bytes)

    PIC18F242016K819276825625102/0
    PIC18F252032K16384153625625102/0
    PIC18F442016K819276825636131/1
    PIC18F452032K16384153625636131/1
