    AD5254B1 Nonvolatile Memory Digital Potentiometers Electronic Component

    Ask Lasest Price
    Brand Name : AD
    Model Number : AD5254B1
    Certification : Original
    Price : 0.1USD
    Payment Terms : T/T, Western Union,Paypal
    Supply Ability : 10000PCS/DAY
    Delivery Time : 1 day
    • Product Details
    • Company Profile

    AD5254B1 Nonvolatile Memory Digital Potentiometers Electronic Component

    AD5254B1 Nonvolatile Memory Digital Potentiometers
    FEATURES
    AD5253: Quad 64-position resolution
    AD5254: Quad 256-position resolution
    1 kΩ, 10 kΩ, 50 kΩ, 100 kΩ Nonvolatile memory stores wiper settings with write protection Power-on refreshed to EEMEM settings in 300 µs typ
    EEMEM rewrite time = 540 µs typ Resistance tolerance stored in nonvolatile memory 12 extra bytes in EEMEM for user-defined information IC® compatible serial interface Direct read/write accesses of RDAC and EEMEM registers Predefined linear increment/decrement commands Predefined ±6 dB step change commands Synchronous or asynchronous quad channel update Wiper setting readback 4 MHz bandwidth—1 kΩ version Single supply 2.7 V to 5.5 V
    Dual supply ±2.25 V to ±2.75 V 2 slave address decoding bits allow operation of 4 devices 100-year typical data retention, TA= 55°C Operating temperature: –40°C to +85°C
    APPLICATIONS
    Mechanical potentiometer replacement Low resolution DAC replacement RGB LED backlight control
    White LED brightness adjustment RF base station power amp bias control Programmable gain and offset control
    Programmable attenuators Programmable voltage-to-current conversion Programmable power supply
    Programmable filters Sensor calibrations
    GENERAL DESCRIPTION
    The AD5253/AD5254 are quad channel,2C, nonvolatile memory, digitally controlled potentiometers with 64/256 positions, respectively. These devices perform the same electronic adjustment functions as mechanical potentiometers, trimmers, and variable resistors.
    The AD5253/AD5254’s versatile programmability allows multiple modes of operation, including read/write accesses in the RDAC and EEMEM registers, increment/decrement of resistance, resistance changes in ±6 dB scales, wiper setting readback, and extra EEMEM for storing user-defined information, such as memory data for other components, look-up table,or system identification information.
    ParameterSymbolConditions
    Input Leakage Current (Other
    than WP and A0)
    IA0
    VIN= 0 V or VDD
    POWER SUPPLIES
    Single-Supply Power Range
    VDD
    VSS= 0 V
    DYNAMIC CHARACTERISTICS
    Bandwidth –3 dB
    BW
    RAB= 1 kΩ
