AT24C512C - SSHD - T electronic ic chip I2C - Compatiable 2 wire Serial EEPROM 512 Kbit

Anterwell Technology Ltd.
Contact Now
    Buy cheap AT24C512C - SSHD - T electronic ic chip I2C - Compatiable 2 wire Serial EEPROM 512 Kbit from wholesalers

    Buy cheap AT24C512C - SSHD - T electronic ic chip I2C - Compatiable 2 wire Serial EEPROM 512 Kbit from wholesalers
    • Buy cheap AT24C512C - SSHD - T electronic ic chip I2C - Compatiable 2 wire Serial EEPROM 512 Kbit from wholesalers

    AT24C512C - SSHD - T electronic ic chip I2C - Compatiable 2 wire Serial EEPROM 512 Kbit

    Ask Lasest Price
    Brand Name : ATMEL
    Model Number : AT24C512C-SSHD-T
    Certification : Original
    Price : 0.1USD
    Payment Terms : T/T, Western Union,Paypal
    Supply Ability : 10000PCS/DAY
    Delivery Time : 1 day
    • Product Details
    • Company Profile

    AT24C512C - SSHD - T electronic ic chip I2C - Compatiable 2 wire Serial EEPROM 512 Kbit

    AT24C512C - SSHD - T electronic ic chip I2C - Compatiable 2 wire Serial EEPROM 512 Kbit
    Features
    Low-voltage and standard-voltage operation 1.7V (VCC= 1.7V to 3.6V)
    2.5V (VCC= 2.5V to 5.5V)
    Internally organized as 65,536 x 8
    2-wire serial interface
    Schmitt Triggers, filtered inputs for noise suppression
    Bidirectional data transfer protocol
    400kHz (1.7V) and 1MHz (2.5V, 5.5V) compatibility
    Write Protect pin for hardware data protection
    128-byte page write mode
    partial page writes allowed
    Random and sequential read modes
    Self-timed write cycle (5ms max)
    High reliability
    Endurance: 1,000,000 write cycles
    Data retention: 40 years
    Green package options (Pb/Halide-free/RoHS Compliant)
    8-lead JEDEC SOIC, 8-lead EIAJ SOIC, 8-lead TSSOP, 8-pad UDFN, and
    8-ball VFBGA packages
    Die sale options: wafer form and tape and reel available
    Description
    The Atmel®AT24C512C provides 524,288 bits of Serial Electrically Erasable andProgrammable Read-Only Memory (EEPROM) organized as 65,536 words of eight bitseach. The cascadable feature of the device allows up to eight devices to share acommon 2-wire bus. The device is optimized for use in many industrial and commercialapplications where low-power and low-voltage operation are essential. The devices areavailable in space-saving 8-lead JEDEC SOIC, 8-lead EIAJ SOIC, 8-lead TSSOP,8-pad UDFN, and 8-ball VFBGA packages. In addition, the entire family is available in1.7V (1.7V to 3.6V) and 2.5V (2.5V to 5.5V) versions.
    Pin Name

    Function

    A0- A2
    Address Inputs
    GND
    Ground
    SDA
    Serial Data
    SCL
    Serial Clock Input
    WP
    Write Protect
    VCCPower Supply

    IC STOCK
    PartNoDescDC
    LFB215G51SG8A15480511+
    BL-HX133-AV-TRB120612+
    BEAD12069OB04SUF120611+
    DS2413BG-100-3CO+T0742NOPB11+
    DEA212450BT-7067A10805+12+
    FAR-F6EB-1G8425-B2BG-ZILCC512+
    NTHD4508NT1G1206A11+
    MPXM2102A5LDM12+
    FX510-N-TL6PIN11+
    S-8201AADBD-M5D-TF6PIN11+
    MQW291A897MR67 912+
    EX128-CS128IBGA12+
    AQ2324BGA11+
    AD6426ABBGA12+
    AD6521ACABGA11+
    AD6654BBCZBGA11+
    AD80028BBCBGA12+
    ADSP-21369KBPZ-3ABGA12+
    ADSP-BF531SBBZ400BGA11+
    ADSP-TS101SAB2-0BGA12+
    ADXRS150AIBGA11+
    ADXRS300AIBGA11+
    AIC-7896NBGA12+
    AD80148BBCZBGA12+
    AD9920BBCZ-RLBGA11+
    AD9923AXBCZBGA12+
    AD9923BBCZRLBGA11+
    AD9923XBCZBGA11+
    AD9925BBCZBGA12+
    AD9927BBCZBGA12+
    AM29LV160DB-120WCIBGA11+
    ADM8211BGA12+
    G-CSP2200B1-YV10-LDYBGA11+
    M-L-PA751604LXA2-CTBGA11+
    WL600114LY-DBBGA12+
    Ai128PROBGA12+
    M1535 B1BGA11+
    M1535-BICBGA12+
    M1535D+A1BGA11+
    M1621 AOBGA11+
    M1647 A1BGA12+
    M4301AUBGA12+
    PS196-315BGA11+
    AL8688-2A80BGA12+
    EP1K30FC256-3BGA11+
    EP1S30F780I6NBGA11+
    EP2A15F672C9BGA12+
    EP2C35F672C8NBGA12+
    EP2C50F672C8NBGA11+
    EP2C70F896C8BGA12+
    EP2C8F256C8NBGA11+
    EP2S30F672C5NBGA11+
    EP3SE110F1152I3NBGA12+
    EPF10K100EFC484-1BGA12+
