    AT29C256-70PC IC 256K 32K x 8 5-volt Flash Memory Electronic Components

    Ask Lasest Price
    Brand Name : ATMEL
    Model Number : AT29C256-70PC
    Certification : Original
    Price : 0.1USD
    Payment Terms : T/T, Western Union,Paypal
    Supply Ability : 10000PCS/DAY
    Delivery Time : 1 day
    • Product Details
    • Company Profile

    AT29C256-70PC IC 256K 32K x 8 5-volt Flash Memory Electronic Components

    AT29C256-70PC IC 256K 32K x 8 5-volt Only CMOS Flash Memory
    Features
    Fast Read Access Time – 70 ns
    5-volt Only Reprogramming
    Page Program Operation
    – Single Cycle Reprogram (Erase and Program)
    – Internal Address and Data Latches for 64 Bytes
    Internal Program Control and Timer
    Hardware and Software Data Protection
    Fast Program Cycle Times
    – Page (64 Byte) Program Time – 10 ms
    – Chip Erase Time – 10 ms
    DATA Polling for End of Program Detection
    Low-power Dissipation
    – 50 mA Active Current
    – 300 µA CMOS Standby Current
    Typical Endurance > 10,000 Cycles
    Single 5V
    ±10% Supply
    CMOS and TTL Compatible Inputs and Outputs
    Commercial and Industrial Temperature Ranges
    256K (32K x 8)
    5-volt Only
    Flash Memory
    AT29C256
    Description
    The AT29C256 is a five-volt-only in-system Flash programmable and erasable read only memory (PEROM). Its 256K of memory is organized as 32,768 words by 8 bits. Manufactured with Atmel’s advanced nonvolatile CMOS technology, the device offers access times to 70 ns with power dissipation of just 275 mW. When the device is deselected, the CMOS standby current is less than 300 µA. The device endurance is such that any sector can typically be written to in excess of 10,000 times.
    Pin Name
    Function
    A0 - A14Addresses
    CEChip Enable
    OEOutput Enable
    WEWrite Enable
    I/O0 - I/O7Data Inputs/Outputs
    NCNo Connect
    DCDon’t Connect
