CONSTRUCTION

The resistor is constructed on top of a high-grade ceramic body. Internal metal electrodes are added on each end to make the contacts to the thick film resistive element. The composition of the resistive element is a noble metal imbedded into a glass and covered by a second glass to prevent environment influences. The resistor is laser trimmed to the rated resistance value. The resistor is covered with a protective epoxy coat, finally the two external terminations (matte tin on Nibarrier) are added.

SCOPE

This specification describes RC1206 series chip resistors with lead-free terminations made by thick film process.

FEATURES

► Halogen Free Epoxy

► RoHS compliant - Products with lead free terminations meet RoHS requirements

- Pb-glass contained in electrodes, resistor element and glass are exempted by RoHS

► Reducing environmentally hazardous wastes

► High component and equipment reliability

► Saving of PCB space

► None forbidden-materials used in products/production
