    INA122UA Single Supply, MicroPower INSTRUMENTATION AMPLIFIER high definition audio realtek

    Ask Lasest Price
    Brand Name : BB
    Model Number : INA122UA
    Certification : Original Factory Pack
    Price : Negotiation
    Payment Terms : T/T, Western Union,PayPal
    Supply Ability : 600PCS
    Delivery Time : 1 Day
    • Product Details
    • Company Profile

    INA122UA Single Supply, MicroPower INSTRUMENTATION AMPLIFIER high definition audio realtek

    STOCK LIST


    ICM7555IPA3426INTERSIL15+DIP8
    LM5025MTCX3440NS12+TSSOP16
    CM1293-08MR3442CMD16+MSOP-10
    LM4853MM3450NS12+MSOP10
    TIP1353450ST16+TO-220
    IRF9640S3455IR16+TO263
    PIC16F57-I/SO3455MICROCHIP16+SOP28
    SSC543470VISHAY16+DO-214AB
    FMMT560TA3477ZETEX16+SOT23
    AD222813500ADI14+LCC8
    ADM705AN3500AD16+DIP
    ATMEGA328P-AU3500ATMEL16+QFP32
    BD1383500ST15+TO-126
    H11L1SR2M3500FAIRCHILD16+SOP-6
    HGTG30N60B33500FSC15+TO-247
    HY62256ALP-103500HY12+DIP
    IRFD120P3500VISHAY16+DIP-8
    L6565D3500ST12+SOP-8
    LM1117DT-3.33500NS16+TO252


    INA122UA

    Single Supply, MicroPower INSTRUMENTATION AMPLIFIER

    FEATURES

    ● LOW QUIESCENT CURRENT: 60µA

    ● WIDE POWER SUPPLY RANGE Single Supply: 2.2V to 36V Dual Supply: –0.9/+1.3V to ±18V

    ● COMMON-MODE RANGE TO (V–)–0.1V

    ● RAIL-TO-RAIL OUTPUT SWING

    ● LOW OFFSET VOLTAGE: 250µV max

    ● LOW OFFSET DRIFT: 3µV/°C max

    ● LOW NOISE: 60nV/√Hz

    ● LOW INPUT BIAS CURRENT: 25nA max

    ● 8-PIN DIP AND SO-8 SURFACE-MOUNT


    APPLICATIONS

    ● PORTABLE, BATTERY OPERATED SYSTEMS

    ● INDUSTRIAL SENSOR AMPLIFIER: Bridge, RTD, Thermocouple

    ● PHYSIOLOGICAL AMPLIFIER: ECG, EEG, EMG

    ● MULTI-CHANNEL DATA ACQUISITION


    DESCRIPTION

    The INA122 is a precision instrumentation amplifier for accurate, low noise differential signal acquisition. Its two-op-amp design provides excellent performance with very low quiescent current, and is ideal for portable instrumentation and data acquisition systems. The INA122 can be operated with single power supplies from 2.2V to 36V and quiescent current is a mere 60µA. It can also be operated from dual supplies. By utilizing an input level-shift network, input commonmode range extends to 0.1V below negative rail (single supply ground).


    A single external resistor sets gain from 5V/V to 10000V/V. Laser trimming provides very low offset voltage (250µV max), offset voltage drift (3µV/°C max) and excellent common-mode rejection. Package options include 8-pin plastic DIP and SO-8 surface-mount packages. Both are specified for the –40°C to +85°C extended industrial temperature range.
