MAX485CPA Low Power Programmable IC Chips Slew Rate Limited Transceivers timer circuit board

Low-Power, Slew-Rate-Limited RS-485/RS-422 Transceivers

♦ For Multiple Transceiver Applications

MAX3030E–MAX3033E: ±15kV ESD-Protected, +3.3V, Quad RS-422 Transmitters

♦ For Fail-Safe Applications

MAX3080–MAX3089: Fail-Safe, High-Speed (10Mbps), Slew-Rate-Limited RS-485/RS-422 Transceivers

♦ For Low-Voltage Applications MAX3483E/MAX3485E/MAX3486E/MAX3488E/ MAX3490E/MAX3491E: +3.3V Powered, ±15kV ESD-Protected, 12Mbps, Slew-Rate-Limited, True RS-485/RS-422 Transceivers

ABSOLUTE MAXIMUM RATINGS

Supply Voltage (VCC).............................................................12V

Control Input Voltage (RE, DE)...................-0.5V to (VCC + 0.5V)

Driver Input Voltage (DI).............................-0.5V to (VCC + 0.5V)

Driver Output Voltage (A, B)...................................-8V to +12.5V

Receiver Input Voltage (A, B).................................-8V to +12.5V

Receiver Output Voltage (RO).....................-0.5V to (VCC +0.5V)

Continuous Power Dissipation (TA = +70°C)

8-Pin Plastic DIP (derate 9.09mW/°C above +70°C) ....727mW

14-Pin Plastic DIP (derate 10.00mW/°C above +70°C) ..800mW

8-Pin SO (derate 5.88mW/°C above +70°C).................471mW

14-Pin SO (derate 8.33mW/°C above +70°C)...............667mW

8-Pin µMAX (derate 4.1mW/°C above +70°C) ..............830mW

8-Pin CERDIP (derate 8.00mW/°C above +70°C).........640mW

14-Pin CERDIP (derate 9.09mW/°C above +70°C).......727mW
