2KBP06M Rectifier Diode Glass Passivated Single - Phase Bridge Rectifier

Anterwell Technology Ltd.
Contact Now
    Buy cheap 2KBP06M Rectifier Diode Glass Passivated Single - Phase Bridge Rectifier from wholesalers

    Buy cheap 2KBP06M Rectifier Diode Glass Passivated Single - Phase Bridge Rectifier from wholesalers
    • Buy cheap 2KBP06M Rectifier Diode Glass Passivated Single - Phase Bridge Rectifier from wholesalers

    2KBP06M Rectifier Diode Glass Passivated Single - Phase Bridge Rectifier

    Ask Lasest Price
    Brand Name : Anterwell
    Model Number : 2KBP06M
    Certification : new & original
    Price : Negotiate
    Payment Terms : T/T, Western Union, Paypal
    Supply Ability : 8400pcs
    Delivery Time : 1 day
    • Product Details
    • Company Profile

    2KBP06M Rectifier Diode Glass Passivated Single - Phase Bridge Rectifier


    2KBP06M Rectifier Diode Glass Passivated Single - Phase Bridge Rectifier


    Stock Offer (Hot Sell)

    Part No.QuantityBrandD/CPackage
    PZT2222A81000FSC13+SOT-223
    PZT2222AT1G54000ON16+SOT-223
    PZTA42T1G35000ON16+SOT-223
    PZTA92T1G36000ON13+SOT-223
    Q13FC135000040038000EPSON13+SMD
    QFET-3000-TR1G16165AVAGO16+SOT-343
    R1LP0408CSB-7LI3865RENESAS16+TSOP-32
    R2A15120FA5054RENESAS14+QFP48
    R2A15908SP7631RENESAS16+SOP-28
    R43638626HARRIS16+TO-263
    R5F100LEAFA#V01933RENESAS12+LQFP-64
    RA30H2127M1228MITSUBISH12+H2S
    RA35H1516M1255MITSUBISH15+DIP
    RB160L-90 TE2565000ROHM15+SOD-106
    RB160M-60155000ROHM14+SOD-123
    RB450F12000ROHM14+SOT-323
    RB551V-309000ROHM16+SOD-323
    RC4558DR31000TI16+SOP-8
    RCLAMP0504F.TCT64000SEMTECH15+SOT-363
    RCLAMP0504S.TCT65000SEMTECH15+SOT23-6
    RCLAMP0524P.TCT158000SEMTECH13+SLP2510P8
    RD06HVF12253MITSUBISH14+TO-220
    REF03GS5373ADI16+SOP-8
    REF192FSZ4252AD13+SOP-8
    REF192GSZ6359AD16+SOP-8
    REF195GSZ3984AD16+SOP-8
    REF198FS-REEL5545AD06+SOP-8
    REF3030AIDBZR4334TI15+SOT-23
    REF3040AIDBZR4160TI15+SOT-23
    REF5020AIDR3759TI16+SOP-8

    2KBP005M thru 2KBP10M, 3N253 thru 3N259

    Glass Passivated Single-Phase Bridge Rectifier


    FEATURES

    • UL recognition file number E54214

    • Ideal for printed circuit board

    • High surge current capability

    • High case dielectric strength

    • Solder dip 260 °C, 40 s

    • Component in accordance to RoHS 2002/95/EC and WEEE 2002/96/EC


    TYPICAL APPLICATIONS

    General purpose use in ac-to-dc bridge full wave rectification for switching power supply, home appliances, office equipment, and telecommunication applications.


    MECHANICAL DATA

    Case: KBPM

    Epoxy meets UL 94V-0 flammability rating

    Terminals: Silver plated leads, solderable per J-STD-002 and JESD22-B102

    E4 suffix for consumer grade

    Polarity: As marked on body


    MAXIMUM RATINGS (TA = 25 °C unless otherwise noted)

    PARAMETERSYMBOL

    2KBP

    005M

    2KBP

    01M

    2KBP

    02M

    2KBP

    04M

    2KBP

    06M

    2KBP

    08M

    2KBP

    10M

    UNIT
    3N2533N2543N2553N2563N2573N2583N259
    Maximum repetitive peak reverse voltageVRRM501002004006008001000V
    Maximum RMS voltageVRMS3570140280420560700V
    Maximum DC blocking voltageVDC501002004006008001000V
    Max. average forward output rectified current at TA = 55 °CIF(AV)2.0A
    Peak forward surge current single half sine-wave superimposed on rated loadIFSM60A
    Rating for fusing (t < 8.3 ms)I2t15A2s
    Operating junction and storage temperature rangeTJ, TSTG- 55 to + 165°C


    PACKAGE OUTLINE DIMENSIONS in inches (millimeters)
