STA516B Electronic IC Chips popular integrated circuits

    Buy cheap STA516B Electronic IC Chips popular integrated circuits from wholesalers

    Buy cheap STA516B Electronic IC Chips popular integrated circuits from wholesalers
    • Buy cheap STA516B Electronic IC Chips popular integrated circuits from wholesalers

    STA516B Electronic IC Chips popular integrated circuits

    Ask Lasest Price
    Brand Name : Anterwell
    Model Number : STA516B
    Certification : new & original
    Price : Negotiate
    Payment Terms : T/T, Western Union, Paypal
    Supply Ability : 7800pcs
    Delivery Time : 1 day
    • Product Details
    • Company Profile

    STA516B Electronic IC Chips popular integrated circuits


    Stock Offer (Hot Sell)

    Part No.QuantityBrandD/CPackage
    LT1933ES62520LT16+SOT23-6
    LT1963AEQ-3.34329LINEAR15+TO-263
    LT3008ETS818224LT16+SOT23-8
    LT3086EFE4480LT16+TSSOP
    LT3494EDDB6707LINEAR15+DFN-8
    LT4363IMS-23550LINEAR14+MSOP
    LT5534ESC6#TRPBF3101LINEAR15+SC70-6
    LT6100IMS86678LINEAR16+MSOP-8
    LT6108IMS8-25119LT16+MSOP-8
    LTC1452IS8#TRPBF1457LINEAR10+SOIC
    LTC1535CSW3037LT10+SOP-28
    LTC1545CG1704LINEAR00+SSOP-36
    LTC1546CG2661LINEAR04+SSOP
    LTC1877EMS8#PBF1638LT15+MSOP-8
    LTC2050CS5#TR15318LINEAR01+SOT23-5
    LTC2924IGN3108LT16+SSOP-16
    LTC2955ITS8-21861LINEAR16+SOT23-8
    LTC3112EDHD3059LT16+QFN16
    LTC3371EUHF#PBF2317LINEAR14+QFN
    LTC3406ES5-1.5#TRPBF9278LINEAR10+SOT23-5
    LTC3454EDD3010LT13+DFN-10
    LTC3545EUD-1#TRPBF2652LINEAR13+QFN16
    LTC3621EMS8E3150LINEAR13+MSOP-8
    LTC3631IMS8E2803LT16+MSOP-8
    LTC3789EUFD2385LINEAR16+QFN
    LTC3850EGN#TRPBF18295LINEAR13+SSOP-28
    LTC3850EUF7490LINEAR15+QFN
    LTC3851EGN3121LINEAR15+SSOP
    LTC4011CFE4687LINEAR08+TSSOP-20
    LTC4054ES5-4.26539LT16+SOT23-5

    STA516B

    60 V 6 A quad power half bridge


    Features

    ■ Minimum input output pulse width distortion

    ■ 200 mΩ RdsON complementary DMOS output stage

    ■ CMOS compatible logic inputs

    ■ Thermal protection

    ■ Thermal warning output

    ■ Under voltage protection


    Description

    STA516B is a monolithic quad half bridge stage in Multipower BCD Technology. The device can be used as dual bridge or reconfigured, by connecting CONFIG pin to Vdd pin, as single bridge with double current capability, and as half bridge (Binary mode) with half current capability.


    The device is particularly designed to make the output stage of a stereo all-digital high efficiency (DDX™) amplifier capable to deliver 160 + 160 W @ THD = 10 % at Vcc 50 V output power on 8 Ω load and 320 W @ THD = 10 % at Vcc 50V on 4 Ω load in single BTL configuration.


    The input pins have threshold proportional to VL pin voltage.


    Absolute maximum ratings

    SymbolParameterValueUnit
    VCCDC supply voltage (Pins 4,7,12,15)60V
    VmaxMaximum voltage on pins 23 to 325.5V
    TopOperating temperature range0 to 70°C
    Tstg, TjStorage and junction temperature-40 to 150°C
